The EDM machine was removed and the male spline
inserted. The team connected an Enerpac RSL20 torque
tool. That torque wrench is capable of 20,000 ft/lbs
of torque. With that much torque, it explains why the
spline fi t and concentricity to the valve stem needed
to be perfect.

With the attention to detail and careful planning on behalf
of all the companies involved, the valve stem rotated and
the correct water fl ow was established, thus eliminating
the need to derate the plant.
EDM Today Magazine EDM Today Magazine EDM Today Magazine
The people that work on our emergent response teams
are a rare breed indeed. They must work in environmen-
tally demanding conditions. Often in high-temperature,
high-humidity conditions for extended times. They are
committed to working back-to-back 12-hour shifts for
days on end. They, of course, need to be highly trained
Figure 5 Inside Centering Screen
and skilled to perform the work with the highest
probability of success. They must also be trained to work safely in a radiologically active environment and
the tight quarters of a typical nuclear plant. There is no doubt these are some real EDM Road Warriors!

FOR MORE INFORMATION

EDM Today Magazine
EDM Today Magazine
EDM Today Magazine Derek Kleinschmidt can be reached at: 3D Graphite can be reached at:

Steve Earney can be reached at:
derek_k@edmzap.com
Steve.Earney@hydratight.com
sales@3dgraphite.com
www.3dgraphite.com
www.hydratight.com
www.edmzap.com
