Check diameter for selected E Code. Examination of the E Code file shows that the diameter for E Code 7 is .0393.

Therefore, when running the program, only electrodes running this diameter will be selected from the tool changer
turret – see Figure 2

Press:

EDM Today Magazine EDM Today Magazine EDM Today Magazine

Press:

Figure 2 Figure 3
EDM Today Magazine EDM Today Magazine EDM Today Magazine
Lastly, verify that the diameter matches in “Tool Length” page. The Tool Length page contains length and diameter
information for the electrode in each turret position. In the example shown in Figure 3, notice the diameter for T1
(Tool 1) differs from that of the rest of the T positions.
