One of the most novel EDAF innovations is the use
of built-in Smart Logic as part of Makino’s Hyper-i
Control. Smart Logic provides a consistent and
smooth fl ow rate to prevent agitation of work tank
fl uid debris – see Figure 2.
EDM Today Magazine EDM Today Magazine EDM Today Magazine
Figure 5 1 VDI Surface Finish
Figure 2 Hyper-i Control Smart Logic Flow Control
media technology that provides a larger fi lter
In addition to the enhancements in tank circulation The new fi lters on the EDAF Series utilize a thin
surface area. As a result, the fl uid cleaning rate
EDM Today Magazine EDM Today Magazine EDM Today Magazine
and fl ow, several improvements have been made to
is 30% faster, and the overall fi lter life has been
the fi ltration system. The new design provides for
increased by 10%. This combination of fl ush and
a direct transfer of clean dielectric fl uid from the
fi ltration enhancements provides a signifi cant
fi ltration system to the work tank – see Figure 3.
improvement in machining environment cleanliness.
Surface fi nishes are more consistent and free from
“pin-holing.” Figure 5 shows a highly magnifi ed
surface fi nish registering 1 on the VDI scale.
The surface consistency is clearly evident.
The cleaner machining environment also supports
improvement in corner edge quality.
Figure 6 shows the very impressive results of test
EDM Today Magazine EDM Today Magazine EDM Today Magazine
cutting to determine edge quality. In Hardened D2
tool steel, the EDAF Series machine was able to
achieve a clean, consistent edge with only 0.0003”
corner radius.
Figure 3 Direct Transfer of Clean Oil
The fi lter canisters and fi lters have been improved
as well. The fi lter canisters have been redesigned to
simplify and streamline the fi lter changing process.
There are only two parts to remove to change fi lters.
EDM Today Magazine EDM Today Magazine EDM Today Magazine
This simplicity reduces time lost due to fi lter
maintenance – see Figure 4.
Figure 6 Edge Quality Test
EDM Today Magazine
EDM Today Magazine EDM Today Magazine (Continued on next page)
Figure 4 Simplifi ed Filter Maintenance
